Continuous Vertical Sealing Machine

About Continuous Vertical Sealing Machine

Continuous Band Sealer VP 770 V - MS

Introduction

It is latest in sealing technology; and ideal for heat sealing of a variety of thermoplastic pouches & bags continuously, speedily & efficiently. It is a heavy duty model of Continuous Band Sealer, available in vertical configuration. It is in great demand due to efficient packaging of both perishable & non-perishable products in terms of protection from potential damages and contamination before reaching at the hand of end customers. It is widely preferred in packaging food, liquids and many more spillable items.

It adopts electronic constant temperature control system and step less speed adjusting transmission mechanism. As an optional attachment, Solid ink wheel, which is provided, can print production date as well as sealing. The printing letters are clear, have available colours, dries immediately & easy to change.

Salient Features / Benefits

• Simple Design & Sturdy Construction
• MS Body
• Vertical Sealing
• Low Maintenance
• High Productivity
• Reliable Sealing Quality
• Very Low Power Consumption
• Suitable for Pack Size of up to 3 Kgs
• Suitable for All Type of  Heat Sealable Material in Every Thickness

Advantages

Speedy Packing

Due to automation, Continuous Band Sealer is able to increase production dramatically. On an average, 20 to 30 plastic bags / pouches can be sealed in a minute. Sealing speed will depend upon operators' efficiency

Labour Cost Savings

It can give output equivalent to 3-4 Manual Sealing Machines thus there is great savings in labour cost.

Low Maintenance

This machine is imported from Taiwan including best parts, components. It is manufactured in the highly developed manufacturing unit in using latest technology. Machine's quality is strictly controlled in various levels of manufacturing based on range critical parameters. Hence quality is assured for continuous, excellent & prolonged machine performance with minimum maintenance.

User Friendly

This machine is easy to operate for long duration due to its simple design &simple technology. As conveyor speed can be customized, machine speed &performance can be easily aligned with Labor's speed & performance.

Leak Prof &Accurate Sealing

Needless to say, sealed bags or pouches by Continuous Band Sealer produces accurate sealing without any leakage compared to any other sealing process.

Target Industries

• Food & Groceries
• Flour Mills
• Seeds
• Dairy Products
• Bakery Products
• Pharmaceuticals
• Chemical Industries
• Cosmetic Products
• Automobile Spare Parts
• Electronic Spares & Components
• Bearing Industries
• Pesticides
• Detergent
• Tobacco & many more.

Technical Specifications

Machine Weight	37 kgs
Brand	Vijaypack
Model Name/Number	VP 770 V-MS
Capacity	2 KGS
Automation Grade	Semi-Automatic
Max. Conveyor Load	4 KGS
Voltage	220 V
Temperature Range	0  300 DEGREE C
Motor Power	500 W
Machine Dimensions	840 MM x 380 MM x 550 MM
Operational Mode	Vertical
I Deal In	New Only
Sealing Speed	0  12 MTR / MIN
Phase	SINGLE
Material	MS BODY
Sealing Width Mm	8,10 MM
Usage/Application	Heat sealing of a variety of thermoplastic pouches & bags
Temperature Controller	Electric constant temperature control system

Robust Construction for Longevity

Manufactured with a durable mild steel (MS) body, this sealing machine promises long service life and dependable operation. The compact dimensions (840 x 380 x 550 mm) and moderate weight (37 kg) allow for easy placement in workspace environments without occupying excessive room, making it ideal for busy packaging units.


High Precision and Versatility

Engineered for 100% sealing accuracy, this semi-automatic vertical band sealer handles diverse bag and pouch materials. It is powered by a 220V supply and uses only 500W, optimizing energy consumption while delivering secure and uniform seals, which is essential for safeguarding product integrity during distribution.


User-Friendly Semi-Automatic Operation

This machines semi-automatic grade simplifies the bag or pouch sealing process. Operators benefit from time-saving automation while retaining control over key aspects of the packaging line. Its ease of use makes it suitable for both experienced staff and new operators, ensuring rapid integration into your workflow.
